Vitrocsa
Turnable Corner Windows
FREEDOM IN EVERY DIRECTION
Product Information
The Turnable Corner system allows for a multitude of sliding panes of glass which can be moved independently of one another and can be completely hidden inside a wall, on the side of a building, or stacked inside a cupboard or a cavity.
Thanks to a unique system of rollers, the panes can move freely in any direction.
They can be sized up to 6 m² (and 250 kg), and either single or double glazed.
By completely removing the panes from the view, and fully opening up the area, the space can be optimised, allowing architects to explore options which were previously unthinkable.
RAILS + FRAMES
- Embedded and concealed in the floor, wall and ceiling
- Frame just 140 mm wide for a birail (mono: 64 mm + 12 mm seal)
- Saline treatment specially adapted for coastal projects
VERTICAL CONNECTION
- 22 mm
- Reinforced for very windy locations or installation at high altitudes
GLAZING
32 mm or 44 mm
CLOSURE MECHANISM
- 1-point closure button (029, 035, 055)
- Two-point closure button
OPTIONS
Turnable corner (up to 250 kg and 6 m² per panel)
