Vitrocsa

Curved Windows

TH+ RANGE

Product Information

Using 32- or 44-mm-thick double or triple glazing, the Vitrocsa TH+ range with the curved system allows for slding glass surfaces with a minimum radius of 3 meters for sliding applications or a minimum radius of 1.5 meters for fixed applications.

The excellent thermal quality of the profiles, in combination with the glass, meets current standards for low energy consumption.

Curved Windows technical drawing

RAILS + FRAMES

  • Embedded and concealed in the floor, wall and ceiling
  • Frame just 140 mm wide for a birail (mono: 64 mm + 12 mm seal)
  • Saline treatment specially adapted for coastal projects

APPLICATIONS

  • Open angle
  • Pocket
  • Motorisation
  • Invisible threshold for one or more tracks

VERTICAL CONNECTION

  • 22 mm
  • Reinforced for very windy locations or installation at high altitudes

GLAZING

  • 32 mm or 44 mm
  • Dimensions according to configuration and glass supplier

LOCK MECHANISM

  • 1-point closure button (029, 035, 055)
  • Two-point closure button
  • Cylinder
  • Range of options for electric closure
  • Alarms
  • RC2 option
